60kW&90kW&120kW&150kW&200kW |
|
Power Input |
Input Rating |
3-phase 400V±15% AC, 45-65Hz |
|
Power Factor |
≥0.99 |
|
Efficiency |
95% |
|
Power Output |
Output Rating |
200V - 750V DC, 250A |
|
Output Power |
60kW /90kW/120kW/150kW/200kW |
|
Protection |
Electrical Protection |
Over current, short circuit, over voltage, under voltage, ground fault, lightning surge, over temperature |
|
User Interface & Control |
Display |
8” TFT-LCD touch screen |
|
Support Language |
English, Spanish, or other languages required |
|
User Authentication |
RFID card reader, user name & password, mobile No. & pin code |
|
Push Buttons |
3 Physical buttons for Multi-functional purpose, Emergency stop |
|
Charge Options |
Charge by duration, by energy, by amount |
|
Environmental |
Operating Temperature |
(-30℃to +55℃) in operation, (-40℃to +75℃) in storage |
|
Humidity |
95% relative humidity, non-condensing |
|
Altitude |
Up to 6000 feet (2000 m) |
|
Mechanical |
Protection |
IP55 |
|
Cooling |
Forced air |
|
Charging Cable Length |
16.4 ft (5 m), straight cable |
|
Dimension (W x H x D) |
600 x1650 x 380 mm |
|
Gross Weight |
420Kg including wood packaging |
|
Communication |
Network Interface |
Ethernet, 4G Module (optional) |
|
OCPP |
OCPP 1.6J |
|
CCS |
DIN70121/ISO15118/IEC61851/SAEJ1772 |
|
CHAdeMO |
JEVS G104 |
|
GB/T |
GB/T 20234.3-2015，GB/T 18487.3-2001,GB/T 27930.3-2015 |
